Land Registry Lease Plans

A compliant lease plan must be drawn to a recognised metric scale — usually 1:100 or 1:200 for the floor plan — with the scale stated on the drawing. The demised area must be clearly edged in red, communal and shared areas shown in green where they affect the demise, and any rights of way or additional rights distinguished by colour. The plan must carry a north point, a scale bar, and labelled floor levels, and be accompanied by an Ordnance Survey based location plan so the land can be identified on the OS map. The plan must not carry disclaimers such as "for identification purposes only".

The most common reasons HM Land Registry rejects a plan are an incorrect or missing scale, a plan printed using "fit to page", missing orientation, ambiguous boundaries, and insufficient detail to identify the property against the OS map. Because our plans are produced by an experienced team that works to the Registry’s practice guides every day, we anticipate these issues before submission. Every plan is quality-checked, drawn at the correct scale, and supplied as correctly scaled prints so your solicitor can submit with confidence.

We prepare Land Registry lease plans for conveyancing solicitors, licensed conveyancers, chartered surveyors, freeholders, managing agents, developers, estate agents and individual leaseholders. Whether you need a single plan for a flat or a programme of plans across a development, we deliver to your timetable and liaise directly with your solicitor where it helps the application progress smoothly.

You receive a draft PDF lease plan for approval, usually within 48 hours of the survey, followed by up to four scaled hard copies printed on A3 or A4 and posted to your chosen address. The plan is registration-ready and meets the standards set out in HM Land Registry’s guidance on preparing plans for applications.
